Bevpure - Formula B50

Bevpure – Formula B50

Size (OD x ID)

Colours

Length

SKU: B50

Category: B50 – Bevpure

$75.60 – $170.10

Description
Additional information

Formula B50 – Food Safe Elastomer Tubing

Product Information Sheet

Main Applications:

Transfer of beer, soft drinks, potable water and juices
Visual monitoring of fluid flow
Low pressure transfer of solids and gases
Very low out gassing – will not impart odour or taste to fluids
Where high flexibility and tight bend radii are required

Features:

Taste tested to confirm “no taint” to carried fluids
High flexibility
Very resilient to impact and kink
Resistant to a wide range of chemicals
FDA approved
Phthalate and BPA free

Material Properties:

Specific Gravity	0.885 +/- 0.02
Tensile Strength	17.5 MPa
Hydraulic Burst Pressure	10 Bar / 150 Psi

Product Specifications:

Product Code	Inside Diameter (mm)	Tolerance (mm)	Nominal OD (mm)	Standard Coil (m)
B50-04	4.0	+0.05 /-0.10	9.0	30
B50-06	6.0	+0.05 /-0.10	9.0	30
B50-08	8.0	+0.05 /-0.10	13.0	30
B50-10	10.0	+0.05 /-0.10	15.2	30
B50-12.7	12.7	+0.05 /-0.10	18.0	30

Weight	N/A
Size (OD x ID)	B50-04 – 4mm x 9mm, B50-06 – 6mm x 9mm, B50-08 – 8mm x 10mm, B50-10 – 10mm x 15.2mm, B50-12.7 – 12.7mm x 18.2mm
Colours	Natural
Length	30m
Specific Gravity	0.885 +/- 0.02
Tensile Strength	17.5 MPa
Hydraulic Burst Pressure	10 Bar / 150 Psi
