E99 – Easyflow
$16.58 – $421.05
Easyflow
Formula E99 – PVC Tubing
Product Information SheetMain Applications:
- Transfer of beverages and potable water
- Visual monitoring of fluid flow
- Wet or dry foodstuff handling
- Low pressure pump discharge lines
- Where high flexibility is required
Features:
- Smooth bore for excellent flow characteristics
- Transparent with blue tint for a clear view of fluid flow
- Very resilient to impact and kink
- Resistant to dilute acids and alkalis
- Safe for food contact – AS2070 Compliant
- Corrosion and abrasion resistant
Material Properties:
| Specific Gravity | 1.23 +/- 0.02 |
|---|---|
| Tensile Strength | 19 MPa |
| Temperature Range | -15 to +60 °C |
| Hydraulic Burst Pressure (maximum) | 7 Bar / 100 Psi |
Colours:
| Transparent Blue Tint |
Product Specifications:
| Product Code | Inside Diameter (mm) | Outside Diameter (mm) | Standard Coil (m) |
|---|---|---|---|
| E99-03 | 3.0 | 5.0 | 30 |
| E99-05 | 5.0 | 8.0 | 30 |
| E99-55 | 5.5 | 9.0 | 30 |
| E99-06 | 6.0 | 9.0 | 30 |
| E99-08 | 8.0 | 11.0 | 30 |
| E99-10 | 10.0 | 13.0 | 30 |
| E99-12 | 12.0 | 16.0 | 30 |
| E99-16 | 16.0 | 20.0 | 30 |
| E99-19 | 19.0 | 23.0 | 30 |
| E99-25 | 25.0 | 31.0 | 30 |
| E99-32 | 32.0 | 37.0 | 30 |
| E99-40 | 40.0 | 47.0 | 15 |
| E99-50 | 50.0 | 58.0 | 15 |
| Weight | N/A |
|---|---|
| Size (ID x OD) | E99-03 – 3.0mm x 5.0mm, E99-05 – 5.0mm x 8.0mm, E99-055 – 5.5mm x 9.0mm, E99-06 – 6.0mm x 9.0mm, E99-064 – 6.4mm, E99-08 – 8.0mm x 11.0mm, E99-10 – 10.0mm x 13.0mm, E99-11 – 11.0mm, E99-12 – 12.0mm x 16.0mm, E99-13 – 13.0mm, E99-16 – 16.0mm x 20.0mm, E99-19 – 19.0mm x 23.0mm, E99-25 – 25.0mm x 31.0mm, E99-32 – 32.0mm x 37.0mm, E99-40 – 40.0mm x 47.0mm, E99-50 – 50.0mm x 60.0mm |
| Colours | Clear |
| Length | Coil 15m, Coil 30m |
