Formula N11 High Pressure - Ledalon 11

Formula N11 High Pressure – Ledalon 11

Size (OD x ID)

Colours

Length

SKU: N11

Category: N11 – High Pressure – Ledalon 11

$51.60 – $1,050.75

Description
Additional information

Formula N11 High Pressure – Ledalon 11
Nylon 11 Tubing

Product Information Sheet

Only available in black.

Main Applications:

High pressure pneumatic and fluid applications
Short length grease lines
High temperature environments
Where crush and fatigue resistances are required

Features:

High pressure capability to 2500 PSI
Excellent resistance to greases, solvents, oils, hydrocarbons and petroleum products
High tensile strength
UV resistant (in black)
Low gas permeability
Resistant to flexural fatigue and vibration

Formula N11

Main Applications:

High pressure pneumatic and fluid applications
Short length grease lines
High temperature environments
Where crush and fatigue resistances are required

Features:

High pressure capability to 2500 PSI
Excellent resistance to greases, solvents, oils, hydrocarbons and petroleum products
High tensile strength
UV resistant (in black)
Low gas permeability
Resistant to flexural fatigue and vibration

Material Properties:

Specific Gravity	1.05 +/- 0.02
Tensile Strength	30.0 MPa
Temperature Range	-20 to 120 °C
Hydraulic Burst Pressure (minimum)	17000 kPa (2500 PSI) @ 20 °C

Colours:

Black (UV Resistant)

Product Specifications:

Product Code	Outside Diameter (mm)	Tolerance (mm)	Nominal ID (mm)	Standard Coil (m)
N11-04	4	+0.05/-0.07	2.4	100
N11-06	6	+0.05/-0.10	3.4	100
N11-08	8 (5/16”)	+0.05/-0.10	4.8	100
N11-10	10	+0.05/-0.10	6.0	100
N11-12	12	+0.05/-0.10	7.0	100
	inch	inch	inch
N11-1/8	1/8”	+.001/-.003	0.075	100
N11-1/4	1/4”	+.001/-.004	0.147	100
N11-3/8	3/8”	+.001/-.004	0.224	100
N11-1/2	1/2”	+.001/-.004	0.303	100

Recommended Temperature / Pressure Range:

º Celsius	-20	0	10	20	40	50	65	80	95	110	120
Working PSI	1100	1075	1050	1000	800	650	525	350	225	150	100

Weight	N/A
Size (OD x ID)	N11-04 – 4mm x 2.4mm, N11-06 – 6mm x 3.6mm, N11-08 – 8mm x 4.8mm, N11-10 – 10mm x 6mm, N11-12 – 12mm x 7.2mm, N11-1/8 – 1/8" x 0.08", N11-3/16 – 3/16", N11-1/4 – 1/4" x 0.17", N11-3/8 – 3/8 x 0.25", N11-1/2 – 1/2" x 0.37"
Colours	Black
Length	Coil 100m, Coil 10m, Reel 100m
