Ultrachem - Formula U80 - Leda Extrusions

Ultrachem – Formula U80

Size (OD x ID)

Colours

Length

Clear

$18.83 – $44.25

Formula U80 – Fluoropolymer (PFA) Tubing

Product Information Sheet

Main Applications:

Exposure to very caustic and corrosive chemicals
High demand on mechanical properties
Extreme temperature environments
Semiconductor and pharmaceutical industries

Features:

Extreme chemical resistance
High temperature capabilities
Excellent environmental stress crack resistance
Low co-efficient of friction
Chemically inert – very high purity
FDA approved

Material Properties:

Specific Gravity	2.15 +/- 0.02
Tensile Strength	27-32 MPa
Temperature Range	up to 260 °C
Hydraulic Burst Pressure (minimum)	10 – 30 Bar

Colours:

Natural

Product Specifications:

Product Code	Outside Diameter mm	Nominal Inside Diameter mm	Working Pressure @ 20 deg C (bar)	Minimum Bend Radius mm
U80-06	6.0	4.0	30	30
U80-08	8.0	6.0	14	65
U80-10	10.0	8.0	10	80
U80-12	12.0	9.0	9	90
Product Code	Outside Diameter inches	Nominal Inside Diameter mm
U80-1/4	1/4″	4.25
U80-3/8	3/8″	7.50
U80-1/2	1/2″	9.70

Weight	N/A
Size (OD x ID)	U80-06 – 6mm x 4mm, U80-08 – 8mm x 6mm, U80-10 – 10mm x 8mm, U80-12 – 12mm x 9mm, U80-1/4 – 1/4" x 4.25mm, U80-3/8 – 3/8" x 7.5mm, U80-1/2 – 1/2" x 9.7mm
Colours	Natural
Length	per metre

Weight

N/A

Size (OD x ID)

U80-06 – 6mm x 4mm, U80-08 – 8mm x 6mm, U80-10 – 10mm x 8mm, U80-12 – 12mm x 9mm, U80-1/4 – 1/4" x 4.25mm, U80-3/8 – 3/8" x 7.5mm, U80-1/2 – 1/2" x 9.7mm

Colours

Natural

Length

per metre
